Advertised on 06/10/2025
AED 1,362,000Location:
UAE - Abu Dhabi
Unit:
1
Price:
AED 1,362,000
Condition:
New
Available
Optimized for Deep Boreholes
Delivers fast up/down hoisting and consistent vertical drilling in small-diameter borehole applications.
Reinforced Drilling Chassis
Telescopic chassis and robust slewing bearing ensure deep foundation stability and safety.
Responsive Power System
EFI engine dynamically adjusts output for quick action and efficient energy use.
Parameters
Base Engine: ISUZU 6HK1
Engine Power: 212/2000kW/rpm
Emission Regulation: China Stage III
Rated Speed: 5~34rpm
Rated Output Torque: 190kN·m
Max. Pile Diameter: 1800mm
Max. Pile Depth: 59/47m
Crowd Force: 180kN
Stroke: 4200mm
Line Pull: 180kN
Overall Height: 21040mm
Operating Weight: 63T
Transport Width: 3210mm
Transport Height: 3560mm
Lifting Capacity: 185kN
Max. Line Speed: 75m/min
Rope Diameter: 28mm
Price: AED 1362000
Request for quote: +971525384269
